Specification: | |
---|---|
Thickness: | |
Quantity: | |
fiber cement roofing
lonrace
class A
yes
black, grey
4.5-18mm
1.2-1.4g/cm3
CE ISO9001
Cellulose Fiber, pulp
Exterior Wall Panel; Partition wall
TEST ITEM | UNIT | TEST RESULT | |
Bending Strength | Mpa | 6MM | Width: >18 |
| | | Length: >14 |
| | 9MM & 12MM-18MM | Width: >16 |
| | | Length: >13 |
Water Absorption | % | <10% | |
Thermal Contraction | % | <0.06(w/mk) (30 °C ) | |
Density | g/cm3 | 1.3-1.4 | |
Freezing Resistance | After 25 Freezing cycles | No Delaminated | |
Combustibility | - | Incombustible (class A) | |
Fire Resistance Limit | Min | 2 Layers Mineral Wool:180 | |
Thermal Conductivity | W/(m • k) | <0.12 | |
Wall Average Acoustical Deduction Factor | dB | 2 Layers 50mm Mineral Wool: 44 | |
Impact Strength | kg/C | :2.0 | |
Watertight | 24h | No Water Drop at the bottom for 24/h |
TEST ITEM | UNIT | TEST RESULT | |
Bending Strength | Mpa | 6MM | Width: >18 |
| | | Length: >14 |
| | 9MM & 12MM-18MM | Width: >16 |
| | | Length: >13 |
Water Absorption | % | <10% | |
Thermal Contraction | % | <0.06(w/mk) (30 °C ) | |
Density | g/cm3 | 1.3-1.4 | |
Freezing Resistance | After 25 Freezing cycles | No Delaminated | |
Combustibility | - | Incombustible (class A) | |
Fire Resistance Limit | Min | 2 Layers Mineral Wool:180 | |
Thermal Conductivity | W/(m • k) | <0.12 | |
Wall Average Acoustical Deduction Factor | dB | 2 Layers 50mm Mineral Wool: 44 | |
Impact Strength | kg/C | :2.0 | |
Watertight | 24h | No Water Drop at the bottom for 24/h |
Specs | Q'ty /1x20ft | Weight (Kgs) | Volume (m3) |
1220mmx2440mmx6mm | 820pcs | 21000 | 20 |
1220mmx2440mmx9mm | 540pcs | 21000 | 20 |
1220mmx2440mmx12mm | 410pcs | 21000 | 20 |
Specs | Q'ty /1x20ft | Weight (Kgs) | Volume (m3) |
1220mmx2440mmx6mm | 820pcs | 21000 | 20 |
1220mmx2440mmx9mm | 540pcs | 21000 | 20 |
1220mmx2440mmx12mm | 410pcs | 21000 | 20 |
